Description
| FEATURES |
Construction: Hand selected laser cut balsa
Vacuum molded cowl and spinner
Rudder and Elevator Control: Wire pushrod
Servo Placement: Mounted in rails on fuselage
Landing Gear: 1/16″ diameter wire front, tail wire skid
requires bending
| INCLUDES |
All balsa, lightweight colored (black and white) tissue covering
two 1-3/4″ (45mm) lightweight foam main wheels, tail wire skid,
lightweight plastic tail wheel, CA hinges and all hardware to
complete kit, instruction manual, two full-size plan sheets,
acetate sheet for windows and vacuum molded cowl and spinner
| REQUIREMENTS |
GWS IPS (indoor power system) motor with “A” ratio gear drive
GWSG2023
3 channel radio system (minimum)
3 micro servos
5A ESC w/BEC GWSM2059
2 cell 700mAh LiPo battery
GWS 9×7 prop, GWSQ2019
Building and field equipment
| SPECIFICATIONS |
Length: 25″ (635mm)
Wingspan: 35″ (889mm)
Wing Area: 352sq.in. (22.74 sq dm)
Airfoil: Flat bottom
Center of Gravity (CG): 3-7/16″ 87.5mm) back from the leading edge
of the TOP wing
Control Throws-
Elevator, Up and Down: 1/2″ (13mm)
Rudder, Left and Right: 1″ (25.5mm)
